UPS LEGEND 650VA

Product Description

Product Description Microtek Legend 650VA UPS

Microtek Legend 650 Line Interactive UPS 650VA/360W / Microtek UPS LEGEND 650 Computer UPS is a line-interactive UPS designed to provide backup power and voltage stabilization for PCs, modems/routers, TVs and other sensitive electronics during mains power fluctuations and outages

Technical Specifications Legend 650VA UPS

Power & Performance

• Model: UPS Legend 650

• Type: Line-Interactive UPS with AVR (Automatic Voltage Regulation)

• Capacity: 650 VA / 360 W output power

• Input Voltage Range: ~140300 V AC (wide range for varying mains)

• Input Frequency: 50 Hz 10 %

• Output Voltage (Battery): 230 V AC nominal

• Output Frequency (Battery): 50 Hz 1 %

• Transfer Time: Typical ~48 ms (fast switch to battery)

• Waveform (Battery Mode): Modified sine wave

Battery

• Type: Sealed Maintenance-Free (SMF) lead-acid

• Battery Rating: ~12 V / 7 Ah 1

• Charging Time: ~68 hrs to ~90 % capacity

• Typical Backup: Depends on connected load (often ~1030 min for a PC & monitor)

Protection Features

• Boost & Buck AVR for stabilizing low/high voltage

• Overload protection, surge protection, short-circuit protection

• Battery over-discharge/over-charge protection

• Cold start function (can start on battery without mains)

• Generator compatibility option

Environment & Build

• Operating Temperature: 0C 40C

• Relative Humidity: 090 % non-condensing

• Noise Level: < 40 dB

• Dimensions: ~281 100 143 mm (LWH)

• Weight: ~4.25 kg (varies by batch)

Warranty

• Typically 2 yrs on electronics + 1 yr on battery (may vary by seller)

What This Means in Practice

• The UPS supplies 360 W of usable power, so its best for desktop PCs, monitors, routers, modems, and networking gear not heavy loads like high-power gaming PCs or large appliances.

• Modified sine wave output works fine with most electronics, but some sensitive audio/video gear or high-end PSUs may behave strangely on battery power.

• Backup time varies a lot with load higher consumption = shorter backup duration


  Specification	Details
  Model	UPS LEGEND 650VA
  Type	Line-Interactive UPS with AVR (Automatic Voltage Regulation)
  Capacity / Output	650 VA / 360 W
  Input Voltage Range	140 V ~ 300 V AC
  Input Frequency	50 Hz 10 %
  Output Voltage (Battery Mode)	230 V AC Nominal
  Transfer Time	Typical 4 8 ms
  Output Waveform (Battery)	Modified Sine Wave
  Battery Type	Sealed Maintenance-Free (SMF)
  Battery Rating	12 V / 7 Ah 1
  Charging Time	~6 8 hrs to ~90 %
  Operating Temperature	0 C 40 C
  Relative Humidity	0 90 % non-condensing
  Noise Level	< 40 dB
  Dimensions (L W H)	~28.1 cm 10 cm 14.3 cm
  Weight	~4.9 kg
  Warranty	~2 yrs on UPS electronics, ~1 yr on battery

  Notes:
  AVR helps stabilize fluctuating mains voltage without switching to battery unnecessarily.
  Modified sine wave output works with most devices but isnt ideal for highly sensitive audio gear
