MICROTEK i MAXX SERIES 5.5 KVA ONLINE UPS 16/18 battery system with isolation transformerLive
62906.0 INR/Unit
Product Details:
- Power Rating 5.5 KVA /4.4 KW
- Product Type ONLINE UPS
- Standard i-MAXX series, 16/18 battery system
- Frequency (MHz) 50 Hertz (HZ)
- Protection Protection Features Overload Protection Automatically limits or disconnects the load if the UPS exceeds its rated capacity to prevent damage to the UPS and connected devices. Short Circuit Protection Immediately shuts down the output in case of a short circuit, safeguarding the UPS and downstream equipment. Over-Voltage Cut-Off (OVCD) Protects connected devices from dangerously high input voltage by disconnecting the UPS until voltage returns to a safe range. Under-Voltage / Low-Voltage Protection Prevents operation under very low mains voltage to avoid malfunction or battery drain. Battery Overcharge & Deep-Discharge Protection Stops overcharging the batteries and prevents deep discharge, enhancing battery life and safety. Surge / Spike Protection Protects sensitive devices from voltage spikes caused by lightning, switching, or grid fluctuations. Over-Temperature Protection Monitors internal UPS temperature and shuts down or throttles operation if it overheats. EMI/RFI Noise Filtering Reduces electromagnetic and radio frequency interference, ensuring clean power for sensitive electronics. Isolation Transformer Protection The built-in transformer isolates the load from mains fluctuations and electrical noise, protecting both UPS and connected devices. Bypass / Maintenance Mode Allows safe maintenance of the UPS without interrupting power supply to connected loads
- Usage POWER SUPPLY
- Size standard
- Click to View more
X
MICROTEK i MAXX SERIES 5.5 KVA ONLINE UPS 16/18 battery system with isolation transformerLive Price And Quantity
- 1 Unit
- 62906.0 INR/Unit
MICROTEK i MAXX SERIES 5.5 KVA ONLINE UPS 16/18 battery system with isolation transformerLive Product Specifications
- 62 Kilograms (kg)
- 0 C to 40 C Celsius (oC)
- i-MAXX series, 16/18 battery system
- Type: 3 core flexible copper cable (for single-phase supply)
- 5.5 KVA /4.4 KW
- POWER SUPPLY
- Digital LCD Display
- 208V/ 220V / 230V AC Volt (V)
- POWER SUPPLY
- Protection Features Overload Protection Automatically limits or disconnects the load if the UPS exceeds its rated capacity to prevent damage to the UPS and connected devices. Short Circuit Protection Immediately shuts down the output in case of a short circuit, safeguarding the UPS and downstream equipment. Over-Voltage Cut-Off (OVCD) Protects connected devices from dangerously high input voltage by disconnecting the UPS until voltage returns to a safe range. Under-Voltage / Low-Voltage Protection Prevents operation under very low mains voltage to avoid malfunction or battery drain. Battery Overcharge & Deep-Discharge Protection Stops overcharging the batteries and prevents deep discharge, enhancing battery life and safety. Surge / Spike Protection Protects sensitive devices from voltage spikes caused by lightning, switching, or grid fluctuations. Over-Temperature Protection Monitors internal UPS temperature and shuts down or throttles operation if it overheats. EMI/RFI Noise Filtering Reduces electromagnetic and radio frequency interference, ensuring clean power for sensitive electronics. Isolation Transformer Protection The built-in transformer isolates the load from mains fluctuations and electrical noise, protecting both UPS and connected devices. Bypass / Maintenance Mode Allows safe maintenance of the UPS without interrupting power supply to connected loads
- AC Input (Mains) Conductor Type: Copper, flexible stranded Core: 3 core (Live, Neutral, Earth) Size: 4 mm 6 mm (depending on load and distance) Insulation: PVC, rated for 300/500 V AC Purpose: Supplies AC power to UPS safely
- 4400 Watt (w)
- 562 mm 250 mm 830 mm Millimeter (mm)
- 50 Hertz (HZ)
- 1 PHASE
- Online Double-Conversion Technology Provides continuous pure sine wave output, eliminating power interruptions and fluctuations. Built-in Isolation Transformer Ensures galvanic isolation, protects sensitive loads from surges, spikes, and electrical noise. Wide Input Voltage Range Operates reliably even with unstable mains voltage. Pure Sine Wave Output Safe for computers, servers, networking equipment, and other sensitive devices. External Battery Support Configurable for 16/18 batteries (12 V SMF/VRLA or tubular), allowing flexible
- STEEL
- 50 Hertz (HZ)
- BLACK
- ONLINE UPS
- standard
- 2 YEAR
MICROTEK i MAXX SERIES 5.5 KVA ONLINE UPS 16/18 battery system with isolation transformerLive Trade Information
- 7 Days
Product Description
Product Description Microtek iMAXX 5.5KVA Online UPS
Microtek iMAXX 5.5kVA 192V Pure Sine Wave Transformer Based Online UPS is a robust online (doubleconversion) UPS system designed to provide uninterrupted and stable power for critical loads such as computers, servers, network equipment, cyber cafes, labs, business equipment and telecom systems. Its especially suitable for environments with frequent power fluctuations, sags, surges and interruptions
Key Bullet Points
-
True Online (DoubleConversion) UPS for uninterrupted power
-
5.5kVA (4.4kW) capacity suitable for medium to heavy loads
-
Transformerbased design with isolation transformer for enhanced protection
-
192V DC battery system using 1618 external batteries
-
Pure sine wave output for clean and stable AC power
-
Wide input voltage range to handle mains fluctuations
-
DSP + IGBT inverter technology for efficient performance
-
Smart LCD/LED status display for realtime monitoring
-
Builtin surge, overload, shortcircuit & battery protections
-
Generator compatible for extended power backup
-
Expandable backup time based on battery capacity (Ah)
-
Ideal for servers, computers, networking equipment, POS, labs, and critical loads
Technical Specification Table
Specification Details Model / Series Microtek iMAXX 5.5kVA / 192V Online UPS Capacity 5.5kVA ( 4.4kW) UPS Type True Online (Double Conversion), Transformerbased Phase Single Phase IN / Single Phase OUT DC System Voltage 192V DC (Adjustable to 216V) Battery System External battery bank 16 / 18 batteries Recommended Battery Type VRLA / SMF or Tubular (adjustable charger cutoff) Battery Charger 2 / 4 / 8A (Default 8A) Input Voltage (Nominal) 208 / 220 / 230VAC Input Voltage Range 165285VAC Input Frequency Range 4055Hz (@50Hz system) Output Voltage 208 / 220 / 230VAC Output Frequency 50Hz (Battery mode 0.1Hz) Voltage Regulation 1% Waveform (Battery Mode) Pure Sine Wave Transfer Time AC Inverter: Zero / Inverter Bypass: 5ms Efficiency 87% (AC) / 91% (Battery) Display & Indication LCD: Load level, battery level, modes, fault indicators Protection Features OVCD (Over Voltage CutOff), Surge protection, Short circuit, Overload, Over temperature Advanced Features Smart Display, EMI/RFI Noise Filter, CVCF, Generator compatible, Maintenance bypass, Optional RS232/USB/SNMP Dimensions (LWH) 562 250 830mm Weight (Approx.) 62kg Operating Conditions 040C, 595% RH Isolation Transformer Builtin for improved protection & isolation
WArranty :- 2 years
Notes-
Backup time depends on the Ah rating of the external batteries you install higher Ah = longer runtime.
-
Designed for mediumtocritical loads like servers, networking gear, POS systems, labs, etc.
-
Compatible with generators (recommended generator size 2.5 UPS capacity).
-
