BPE (MF3110L16) 10KVA ONLINE UPS EXTERNAL BATTERY

95000.0 INR/Unit

Get a Price/Quote

Product Details:

Power Rating 10 kVA
Product Type BPE (MF3110L16) 10KVA ONLINE UPS EXTERNAL BATTERY
Standard IEC 62040 1 / IS 13252 Part 1 / EN 62040 1 (ensures electrical safety)
Frequency (MHz) 50 Hertz (HZ)
Protection Short circuit, overload, over/under voltage, battery low, thermal protection, etc. (standard UPS protections)
Usage BAckup
Size STANDARD
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

BPE (MF3110L16) 10KVA ONLINE UPS EXTERNAL BATTERY Price And Quantity

Price 95000.0 INR/Unit
Minimum Order Quantity 1 Unit

BPE (MF3110L16) 10KVA ONLINE UPS EXTERNAL BATTERY Product Specifications

Usage BAckup
Cable Type ~16 mm copper flexible cable
Product Type BPE (MF3110L16) 10KVA ONLINE UPS EXTERNAL BATTERY
Material STEEL
Standard IEC 62040 1 / IS 13252 Part 1 / EN 62040 1 (ensures electrical safety)
Usage & Applications POWER SUPPLY
Rated Voltage 380 V / 400 V / 415 V AC Volt (V)
Features Wide Input Voltage & Frequency Range Adapts to unstable mains or generator supply.
Frequency (MHz) 50 Hertz (HZ)
Dimension (L*W*H) Dimensions (UPS Unit Only) Width: 192 mm Depth: 460 mm Height: 350 mm Net Weight: ~33 kg Millimeter (mm)
Power Rating 10 kVA
Color black
Rated Current 8 kW (8000 W) Watt (w)
Operating Temperature 0 50 C Celsius (oC)
Weight 100 kg Kilograms (kg)
Frequency 50 Hertz (HZ)
Display Type Multi function LCD Display: Shows detailed UPS status information such as input voltage, output voltage, battery voltage, load level, frequency, and operation mode (online, battery, bypass etc.). It also displays alarms and fault conditions.
Protection Short circuit, overload, over/under voltage, battery low, thermal protection, etc. (standard UPS protections)
Size STANDARD
Warranty 1 YEAR
Phase 1 PHASE

BPE (MF3110L16) 10KVA ONLINE UPS EXTERNAL BATTERY Trade Information

Delivery Time 7 Days

Product Description

Product Description Mfii3110L16 BPE Online UPS (10kVA, External Battery)

The Mfii3110L16 BPE Online UPS is a commercialgrade online uninterruptible power supply (UPS) designed to provide clean, reliable power backup for critical loads such as servers, networking equipment, industrial systems, and sensitive electronics. It features true online doubleconversion technology for consistent output unaffected by input fluctuations.

Specification BPE MFII3110L16 10kVA Online UPS

Specification	Details
Model	MFII3110L16 (External Battery)
Type	True Online DoubleConversion UPS
Rated Power	10kVA / ~8kW
Input Voltage (Nominal)	380/400/415V AC (3P + N + PE)
Input Voltage Range	208480V AC (load dependent)
Input Frequency Range	50/60Hz 10% (autosensing)
Input Power Factor	0.99
Output Voltage (Configurable)	220/230/240V AC L+N+PE
Output Power Factor	1.0 (unity)
Voltage Regulation	1%
Frequency (Battery Mode)	50/60Hz 0.5Hz (configurable)
Crest Factor	3:1
Harmonic Distortion (THDv)	1%
Overload Capability	105% continuous; 125% for 10min; 150% for 60s
Efficiency	~94% (Online mode), ~99% (ECO mode)

Battery & Runtime (External)

Features

Feature	Details
Transfer Time	Zero (instant switchover on mains failure)
Generator Compatible	Yes (input compatible)
ECO Mode	Yes (energysaving mode)
Bypass Range	40% to +15% (configurable)
Protection	Short circuit, overload, over/under voltage, battery low, thermal protection, etc. (standard UPS protections)

Physical & Environmental

Notes:

This unit does not include batteries you must provide an external battery bank sized for the desired backup time.
The DC battery voltage (192/216/240V) is configurable; larger battery string = longer runtime.
Efficiency and exact performance may vary slightly based on configuration and load.

If you want, I can also give you a battery bank sizing table (number of 12V batteries and AH rating) for a specific backup time and load (in watts). Just tell me your load and how long you want the UPS to run!
