LUMINOUS (LB1000XL)Line interactive UPS

BPE (MF1106L16) 6KVA ONLINE UPS EXTERNAL BATTERY Price : 45000.0 INR/Unit Minimum Order Quantity : 1 Product Type : BPE (MF1106L16) 6KVA ONLINE UPS EXTERNAL BATTERY Rated Voltage : 110 V 300 V AC Volt (V) Weight : 26.7 Kilograms (kg) Usage : BACKUP Display Type : LCD & LED panels with mode, voltages, load %, battery status Material : STEEL Dimension (L*W*H) : UPS Unit Dimensions: Height: 399 mm Width: 469 mm Depth: 192 mm Net Weight: ~26.7 kg Millimeter (mm) Power Rating : 6 kVA (6000 VA) Usage & Applications : POWER SUPPLY Size : STANDARD Standard : BIS, IEC/EN62040 series, RoHS, CE* Frequency (MHz) : 50/60 Hertz (HZ) Color : BLACK Phase : SINGLE PHASE Frequency : 50/60 Hertz (HZ) Warranty : 1 YEAR Rated Current : 4800 W Watt (w) Protection : Overload, short circuit, input under/over voltage, over temp, battery low, surge protection Cable Type : Recommended Size: 6 mm to 10 mm copper Operating Temperature : 0 50 C Celsius (oC) Features : True Online Double Conversion Topology

BPE (MF1103B8) 3KVA ONLINE UPS INBUILT BATTERY Price : 24200.0 INR/Unit Minimum Order Quantity : 1 Product Type : BPE (MF1103B8) 3KVA ONLINE UPS INBUILT BATTERY Rated Voltage : 220 / 230 / 240 V AC Volt (V) Weight : 26.7 kg Kilograms (kg) Usage : BACKUP Display Type : Multifunction LCD panel Material : STEEL Dimension (L*W*H) : Specification Value Width (W) ~19.2 cm (~192 mm) Height (H) ~39.9 cm (~399 mm) Depth (D) ~46.9 cm (~469 mm) Form Factor Tower UPS Net Weight ~26.7 kg (approx.) Millimeter (mm) Power Rating : 3000 VA (3 kVA) Usage & Applications : POWER SUPPLY Size : STANDARD Standard : Standard / Certification Details / Purpose BIS Bureau of Indian Standards ensures compliance with Indian safety and performance norms. (bpee.com ) CE Conformit Europ enne indicates compliance with EU safety, health, and environmental requirements. (sinewavebatteries.com ) ISO 9001 / 14001 Quality management (9001) and environmental management (14001) standards. (inrdeals.com ) OHSAS 18001 / ISO 27001 Occupational health & safety management (OHSAS) and information security management (27001). (sinewavebatteries.com ) RoHS Restriction of Hazardous Substances ensures the UPS is environmentally friendly with restricted toxic elements. (inrdeals.com ) Safety Features Compliance Meets global standards for overload, shortcircuit, surge, and deepdischarge protection. (shop.clarioncomputers.in ) Frequency (MHz) : 50 Hertz (HZ) Color : BLACK Phase : Single Phase Frequency : 50 Hertz (HZ) Warranty : 1 YEAR Rated Current : 2400 W Watt (w) Protection : Protection Features Protection Type Description Overload Protection Automatically limits output if load exceeds rated capacity; UPS switches to bypass or alarm. Short Circuit Protection Trips instantly to prevent damage to UPS and connected devices. Overvoltage Protection Protects against input voltage spikes from mains or generator. Undervoltage / Brownout Protection Prevents damage from low input voltage; automatically switches to battery mode if needed. Surge & Spike Protection Shields sensitive equipment from lightning or switching surges. Thermal / Overheat Protection UPS shuts down or alarms if internal temperature exceeds safe limits. Battery Deep Discharge Protection Prevents battery damage by shutting down before voltage drops too low. Battery Overcharge Protection Charger automatically limits voltage to prevent battery overcharging. Input Phase Failure / Phase Reversal Protection Protects UPS in case of incorrect wiring or phase loss. Bypass / Maintenance Mode Protection Ensures safe switching to bypass during UPS servicing. Alarm Indicators Audible and visual alarms for overload, battery low, battery fault, input/output abnormality. Cable Type : This cable plugs into a grounded three pin socket (1P+N+PE). Operating Temperature : ~0 45 C Celsius (oC) Features : Core Features True Online Double Conversion Technology Provides continuous clean power with zero transfer time from mains to battery. Ideal for sensitive electronics like servers, PCs and networking gear. Uses advanced digital control and PWM technology for stable power delivery. Built In Battery Backup Comes with 8 12 V 7 Ah internal sealed lead acid batteries for compact all in one backup. Integrated battery management with deep discharge protection and regulated charging helps prolong battery life. Advanced Monitoring & Control LCD display shows real time information like input/output voltages, frequency, battery level, load %, operation mode, and fault indications. Visual + audible alarms for status changes and protection events. Comprehensive Protection Suite Overload protection: Automatically protects the UPS and connected devices. Short circuit protection: Prevents damage from electrical faults. Surge and spike suppression: Protects against transient voltage spikes. Automatic Voltage Regulation (AVR): Stabilises under /over voltage without switching to battery whenever possible. Wide Input Compatibility Supports wide input voltage range ( 100 300 V AC), helping it handle brownouts and voltage fluctuations without switching to battery prematurely. Works with standby generators and other backup sources. Clean & Stable Output Pure sine wave output ensures safe operation of critical loads and sensitive equipment. High power factor output ( 0.8) and low harmonic distortion help maximise usable capacity. Reliability & Efficiency High dual conversion efficiency ( 94 %) and up to ~99 % in ECO mode for energy savings. Designed with IGBT based inverter/rectifier for robust performance. Other Useful Features Cold start / auto start capability can be started even without mains supply. Static bypass and manual bypass for maintenance or fault scenarios. Compatible with generator and solar assisted systems. Typical Use Cases This UPS is suited for: Home and small office servers & workstations Networking equipment (routers, switches) Security systems (CCTV cameras/DVR/NVR) Critical workstations, POS systems, and telecom gear Any sensitive load requiring uninterrupted pure sine wave power

BPE (MP1102L6) 2KVA ONLINE UPS EXTERNAL BATTERY Price : 42826.0 INR/Unit Minimum Order Quantity : 1 Product Type : BPE (MP1102L6) 2KVA ONLINE UPS EXTERNAL BATTERY Rated Voltage : 220 240 V AC Volt (V) Weight : 26.7 kg Kilograms (kg) Usage : backup Display Type : LCD Display Material : steel Dimension (L*W*H) : Parameter Dimension Height 399 mm Width 192 mm Depth 469 mm Weight ~26.7 kg Millimeter (mm) Power Rating : 2 KVA Usage & Applications : power supply Size : Parameter Size Height 399 mm Width 192 mm Depth 469 mm Weight ~26.7 kg Standard : ISO 9001:2015 Frequency (MHz) : 40 70 Hz Hertz (HZ) Color : black Phase : single phase Frequency : 40 70 Hz Hertz (HZ) Warranty : 1 year Rated Current : 7 8 Amps Ampere (amp) Protection : Overload, short circuit, surge protection Cable Type : 3 Core Copper Cable (Phase + Neutral + Earth) Operating Temperature : 0 40 C Celsius (oC) Features : True Online Double Conversion Technology Ensures continuous, clean power with zero transfer time Pure Sine Wave Output Safe for sensitive equipment like servers, PCs, and medical devices PWM & IGBTBased Design Improves efficiency and reliability

MICROTEK 30 KVA ONLINE UPS 3 PHASE IN 3 PHASE OUT without isolation transformer Price : 299711.0 INR/Unit Minimum Order Quantity : 1 Product Type : ONLINE UPS Rated Voltage : 380 415 V AC Volt (V) Weight : 88 Kilograms (kg) Usage : BACKUP Display Type : 4.3inch Color Touch Panel Material : STEEL Dimension (L*W*H) : 30 cm 81.5 cm 100 cm Centimeter (cm) Power Rating : 30 kVA / 30 KW Usage & Applications : POWER SUPPLY Size : STANDARD Standard : Electrical & Safety Frequency (MHz) : 50 Hertz (HZ) Color : BLACK Phase : 3 PHASE IN 3 PHASE OUT Frequency : 50 Hertz (HZ) Warranty : 1 YEAR Rated Current : 30,000W Watt (w) Protection : ShortCircuit
