MICROTEK 40 KVA ONLINE UPS 3 PHASE IN 3 PHASE OUT without isolation transformer

Product Description

General Description

This is a true online doubleconversion UPS designed to provide clean, uninterrupted power for mediumtolarge industrial or commercial loads (servers, networking, machinery, critical equipment, etc.). It takes 3phase AC input and delivers 3phase AC output with high stability and reliability. It is optimized for areas with harsh power conditions (voltage fluctuations, spikes, frequency variation) and is generator compatible.

Core Features

• True DoubleConversion Online Topology: Converts incoming AC to DC then back to AC to provide pure sine wave output with very low distortion for sensitive electronics.

• Unity Power Factor Output: Ensures efficient use of capacity and better performance with modern loads.

• DSP + IGBT Technology: Advanced Digital Signal Processor control with highfrequency IGBT inverter for high efficiency, lower heat and stable output.

• Active Power Factor Correction (PFC): Helps manage input power quality and reduces stress on upstream supply.

• LCD / Touch Display: Shows realtime status input/output voltages, load, battery status, alarms. (4.3 LCD on many Super Max+ models)

• Generator Compatible: Can work smoothly with a backup generator; builtin timedelay / protections help manage switchovers.

• BuiltIn Bypass Switches: Includes maintenance bypass + static bypass, so loads can be powered even during servicing.

• Adjustable Battery Bank: External batteries (VRLA/SMF or tubular) are connected, with flexibility for runtime planning.

Electrical & Performance Highlights

• Input: 3Phase (typically 380415V AC), wide voltage & frequency tolerance.

• Output: 3Phase (380/400/415V AC), pure sine wave, highly regulated.

• Output Power Factor: 0.99 (often specified as unity) for efficient load delivery.

• Frequency Range: Auto sensing 50Hz/60Hz with synchronized operation possible.

• Parallel Capability (Optional): Up to 3 units can be paralleled for redundancy or capacity increase.

Protection & Reliability

• Surge / Overvoltage Protection: Protects connected equipment from power spikes.

• Short Circuit & Overload Protections: Safeguards the UPS and the load.

• ECO Mode: For energy saving when mains quality is good.

Installation & Use

• External Battery Pack Required: Batteries are not internal must be sized per desired backup time.

• Tower Form Factor: Typically a freestanding unit floor mounted.

• Maintenance Features: It often includes coldstart (can start on battery only), hotstandby and easy service access.
