BPE (MP1102L6) 2KVA ONLINE UPS EXTERNAL BATTERY

Product Description

Heres the description and key specifications for the BPE MFX1102L6 2KVA Online UPS (also commonly referred to as BPE MF1102L6), a 2kVA Online UPS with external battery support:

Overview

• Type: Online UPS (DoubleConversion) provides continuous, clean power without switching delay when mains fails (ideal for sensitive electronics).
• Capacity: 2kVA / 1.6kW output capability.
• Phase: Singlephase input & output (1:1).
• Battery Support: Designed for external SMF batteries (no internal battery included). Typically requires 6 12V batteries in series to make ~72V DC.

Input & Output

• Input Voltage: ~220240V AC, accepts wide mains range.
• Output Voltage: ~220240V AC pure sine wave.
• Efficiency: ~94% in online mode, higher in ECO mode.
• Frequency: Autosensing 50/60Hz.
• Transfer Time: Essentially zero (true online).

Battery & Runtime

• Battery DC Bus: 72V (external batteries).
• Charger Current: ~6A (charges batteries when mains is present).
• External Batteries: You choose the capacity (AH) higher AH = longer runtime (e.g., ~1015min at smaller AH, ~5060min at mid AH).
• Battery Configuration: Usually 6 12V in series for 72V system.

Load Handling & Protection

• Power Factor: ~0.8.
• Output Waveform: Pure sine wave.
• Output THD: <2% (clean output).
• Surge & Noise Filtering: Builtin protection and noise filtering.
• Bypass: Automatic internal bypass in case of fault or maintenance.

Features & Interfaces

• Display: Multifunction LCD for status and settings.
• Communication Ports: RS232 & optional SNMP slot for monitoring.
• Generator & Solar Compatible: Works with generator or solar setups.
• Audible Alarm: Alerts for faults and statuses.

Usage & Installation

• Installation: Place in dry, ventilated area; connect to batteries before use.
• Backup Time: Depends on external battery rating; battery set sold separately.
• Common Configurations:
  • Basic 1015min runtime (smaller AH batteries).
  • ~5060min (mid AH).
  • ~100120min (larger AH).

In short: This is a 2kVA online UPS that runs on external batteries you install yourself, giving clean, uninterrupted power and the flexibility to scale battery backup time based on your battery choice.

If you want, I can list recommended compatible batteries (with prices) that work well with this UPS. Just let me know the backup time youre targeting!

Specification BPE MFX1102L6 2kVA Online UPS (External Battery)

Specification	Details
Model	MFX1102L6 (2kVA, Online UPS)
UPS Type	True Online / Double Conversion
Capacity	2kVA / 1.6kW
Input Voltage	220/230/240V AC (Singlephase, 1Ph+N+PE)
Input Voltage Range	~110300V AC (load dependent)
Input Frequency	50/60Hz Autosensing
Input Power Factor	>0.99
Output Voltage	220/230/240V AC 1%
Output Frequency	Sync Mode 50/60Hz 110% Battery Mode 50/60Hz 0.1Hz
Output Waveform	Pure Sine Wave
Crest Factor	3:1
Efficiency	~94% Dual Conversion / ~99% ECO Mode
Battery DC Bus	72V (external batteries)
Battery Supported	6 12V SMF batteries (external)
Charge Current	~6A (configurable)
Typical Recharge Time	45hours for ~90% capacity
Display/Indicators	LCD (status, battery voltage, load %, fault codes)
Protection	Overload, Short Circuit, Battery Low/High, Fan Fault, UPS Fault
Communication	RS232 standard; optional SNMP/ModBus/USB/RS485
Generator Compatible	Yes
Operating Temperature	045C
Humidity	095% (noncondensing)
Weight	~26.7kg (UPS unit)
Dimensions (approx)	~399mm 192mm 469mm
Wave Type	Pure sine wave output
Approvals/Standards	BIS + CE + IEC/EN standards

WARRANY :-1YEAR
Notes:

• This UPS unit supports external batteries only you need to connect your own SMF batteries (commonly 6 units of 12V to form a 72V DC bank).
• Backup time depends on the battery capacity (AH) you choose higher AH = longer runtime.

Would you like a recommended list of compatible batteries (with prices) for specific backup times (e.g., ~30min, ~1hr, ~2hr)? I can prepare that too.
