ELNOVA (80k33) 80KVA 3:3 PHASE ONLINE UPS

430000.0 INR/Piece

Get a Price/Quote

Product Details:

Power Rating 80KVA
Product Type ELNOVA (80k33) 80KVA 3:3 PHASE ONLINE UPS
Standard IP20
Frequency (MHz) 40 70 Hz Hertz (HZ)
Protection Overload, Short Circuit, Battery Low, Over Temperature
Usage BACKUP
Size 690 720 1400 mm
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

ELNOVA (80k33) 80KVA 3:3 PHASE ONLINE UPS Price And Quantity

Minimum Order Quantity 1 Unit
Price 430000.0 INR/Piece

ELNOVA (80k33) 80KVA 3:3 PHASE ONLINE UPS Product Specifications

Size 690 720 1400 mm
Rated Voltage 380 / 400 / 415 VAC Volt (V)
Operating Temperature 0 C to 40 C Celsius (oC)
Power Rating 80KVA
Standard IP20
Protection Overload, Short Circuit, Battery Low, Over Temperature
Warranty 1 YEAR
Cable Type 4-Core or 5-Core Copper XLPE/PVC Armoured Cable
Weight 518 Kilograms (kg)
Frequency 40 70 Hz Hertz (HZ)
Dimension (L*W*H) 690 720 1400 mm Millimeter (mm)
Phase 3:3 PHASE
Usage & Applications POWER SUPPLY
Frequency (MHz) 40 70 Hz Hertz (HZ)
Rated Current 115.5 A Ampere (amp)
Material STEEL
Display Type LCD + LED Display
Product Type ELNOVA (80k33) 80KVA 3:3 PHASE ONLINE UPS
Color BLACK
Features Provides continuous, clean, and regulated power with zero transfer time during mains failure.
Usage BACKUP

ELNOVA (80k33) 80KVA 3:3 PHASE ONLINE UPS Trade Information

Delivery Time 7 Days

Product Description

ELNOVA 80K33 (80 kVA, 3-Phase In / 3-Phase Out Online UPS) Description

The ELNOVA 80K33 is a high-capacity true online double-conversion UPS designed to provide uninterrupted, clean, and regulated power for mission-critical applications. It uses advanced DSP digital control technology and input power factor correction to ensure stable output voltage and protection against power disturbances such as outages, surges, sags, harmonics, and frequency fluctuations.

ELNOVA 80K33 (80 kVA, 3:3 Phase Online UPS) Specifications

Specification	Details
Model	ELNOVA 80K33 / KL80K33
UPS Type	True Online Double Conversion UPS
Capacity	80 kVA
Active Power	64 kW
Input Phase	3 Phase
Output Phase	3 Phase
Input Voltage	380 / 400 / 415 VAC
Output Voltage	380 / 400 / 415 VAC
Input Frequency	50 / 60 Hz
Frequency Range	4070 Hz
Input Power Factor	0.99
Output Power Factor	0.8
Output Waveform	Pure Sine Wave
Voltage Regulation	1%
Output THD	<3% (Linear Load), <5% (Non-Linear Load)
Battery Bus Voltage	384 VDC
Battery Type	External SMF / VRLA Battery Bank
Efficiency	Up to 93%
Transfer Time	0 ms
Overload Capacity	110% for 60 min, 125% for 10 min, 150% for 1 min
Parallel Operation	Up to 6 UPS Units
Communication Ports	RS-232, USB, Optional SNMP
Display	LCD + LED Display
Protection	Overload, Short Circuit, Battery Low, Over Temperature
Operating Temperature	0C to 40C
Protection Class	IP20
Installation	Indoor, Hardwired 5-Wire (3PH + N + G)
Applications	Data Centers, Hospitals, Telecom, Industrial Automation, Manufacturing Plants, IT Infrastructure

Key Features

DSP-based digital control technology
High input power factor correction
Generator compatible
Intelligent battery management
Static and maintenance bypass
Parallel redundancy capability
Zero transfer time during mains failure
Pure sine-wave output for sensitive equipment
