Luminous

ELNOVA (40k33) 40KVA 3:3 PHASE ONLINE UPS

265499.0 INR/Piece

Get a Price/Quote

Product Details:

Product Type ELNOVA (40k33) 40KVA 3:3 PHASE ONLINE UPS
Power Rating 40KVA
Standard Uninterruptible Power Systems (UPS) Safety Requirements
Frequency (MHz) 40 70 Hz Hertz (HZ)
Protection Automatically supports overload conditions up to 110% 150% with controlled shutdown and alarm
Usage BACKUP
Size 828 250 868 mm
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

ELNOVA (40k33) 40KVA 3:3 PHASE ONLINE UPS Price And Quantity

Price 265499.0 INR/Piece

ELNOVA (40k33) 40KVA 3:3 PHASE ONLINE UPS Product Specifications

Cable Type Copper, XLPE insulated, armored (preferred for industrial use)
Warranty 1 YEAR
Color BLACK
Dimension (L*W*H) 828 250 868 mm Millimeter (mm)
Standard Uninterruptible Power Systems (UPS) Safety Requirements
Operating Temperature 0 C to 45 C Celsius (oC)
Product Type ELNOVA (40k33) 40KVA 3:3 PHASE ONLINE UPS
Rated Current 52 A per phase Ampere (amp)
Usage & Applications POWER SUPPLY
Size 828 250 868 mm
Frequency (MHz) 40 70 Hz Hertz (HZ)
Rated Voltage 380V / 400V / 415V AC Volt (V)
Weight 73 Kilograms (kg)
Material STEEL
Protection Automatically supports overload conditions up to 110% 150% with controlled shutdown and alarm
Usage BACKUP
Power Rating 40KVA
Frequency 40 70 Hz Hertz (HZ)
Phase 3:3
Features Overload, Short Circuit, Battery Low Voltage, Over Temperature, Fan Fault
Display Type LCD + LED Display

ELNOVA (40k33) 40KVA 3:3 PHASE ONLINE UPS Trade Information

Delivery Time 7 Days

Product Description

The ELNOVA 40K33 is a high-frequency, three-phase online UPS designed to provide uninterrupted and clean power for critical applications. It uses true online double-conversion technology with DSP digital control, ensuring stable voltage and frequency output while protecting sensitive equipment from power disturbances such as voltage fluctuations, surges, spikes, harmonics, and outages.

ELNOVA 40K33 (40 kVA, 3:3 Phase Online UPS) Specifications

Specification	Details
Model	ELNOVA ES40K33
UPS Type	Online Double Conversion
Capacity	40 kVA / 36 kW
Input Phase	3 Phase + Neutral + Earth (3PH+N+PE)
Output Phase	3 Phase + Neutral + Earth (3PH+N+PE)
Rated Input Voltage	380V / 400V / 415V AC
Input Voltage Range	208478 VAC (depending on load)
Input Frequency Range	4070 Hz
Input Power Factor	0.99
Input THDi	< 3%
Rated Output Voltage	380V / 400V / 415V AC (selectable)
Output Power Factor	0.9
Output Voltage Regulation	1%
Output Waveform	Pure Sine Wave
Output THD	2% (Linear Load)
Crest Factor	3:1
Efficiency (Online Mode)	Up to 94%
Efficiency (ECO Mode)	Up to 99%
Transfer Time	0 ms
Overload Capacity	110% for 60 min, 125% for 10 min, 150% for 1 min
Battery Type	VRLA / SMF Batteries
Battery Bus Voltage	384480 VDC
Maximum Charging Current	20 A
Battery Quantity	3240 Batteries (configurable)
Parallel Redundancy	Up to 4 Units
Display	LCD + LED Display
Communication Ports	RS-232 (Standard), USB/SNMP/RS-485 (Optional)
Protection Features	Overload, Short Circuit, Battery Low Voltage, Over Temperature, Fan Fault
Generator Compatibility	Supported
Isolation Transformer	Optional
Operating Temperature	0C to 45C
Relative Humidity	095% RH (Non-condensing)
Protection Class	IP20
Dimensions (D W H)	828 250 868 mm
Net Weight	73 kg
Compliance	IEC/EN 62040, CE, BIS

The ES40K33 uses DSP-controlled online double-conversion technology with IGBT rectifier/inverter design, providing clean and uninterrupted power for data centers, industrial automation, telecom systems,
