MICROTEK 30 KVA ONLINE UPS 3 PHASE IN 3 PHASE OUT without isolation transformer
Product Details:
- Product Type ONLINE UPS
- Power Rating 30 kVA / 30 KW
- Standard Electrical & Safety
- Frequency (MHz) 50 Hertz (HZ)
- Protection Short-Circuit
- Usage BACKUP
- Size STANDARD
- Click to View more
MICROTEK 30 KVA ONLINE UPS 3 PHASE IN 3 PHASE OUT without isolation transformer Price And Quantity
- 299711.0 INR/Unit
- 1 Unit
MICROTEK 30 KVA ONLINE UPS 3 PHASE IN 3 PHASE OUT without isolation transformer Product Specifications
- 50 Hertz (HZ)
- 4.3-inch Color Touch Panel
- 30,000W Watt (w)
- Short-Circuit
- Electrical & Safety
- 30 cm 81.5 cm 100 cm Centimeter (cm)
- 88 Kilograms (kg)
- BLACK
- STANDARD
- BACKUP
- ONLINE UPS
- 30 kVA / 30 KW
- 50 Hertz (HZ)
- POWER SUPPLY
- 1 YEAR
- 3 PHASE IN 3 PHASE OUT
- STEEL
- 380 415 V AC Volt (V)
MICROTEK 30 KVA ONLINE UPS 3 PHASE IN 3 PHASE OUT without isolation transformer Trade Information
- 7 Days
Product Description
General Description
Product: Microtek 30 kVA Online UPS (3 Phase In 3 Phase Out)
Technology: True double-conversion online UPS AC mains DC AC to provide fully regulated, continuous power with pure sinewave output.
This type of UPS is designed for industrial, commercial, and mission-critical applications (servers, PLCs, CNC machines, medical equipment, telecom, data centers) where grid power is unreliable and clean, continuous power is needed.
Key Technical Features
Input / Output Configuration: 3-Phase input 3-Phase output
Rated Capacity: 30 kVA ( 30 kW)
Online Double-Conversion: Provides isolation from mains fluctuations by constantly inverting mains power DC regulated AC.
True Unity Output Power Factor: Efficient power delivery and compatibility with modern loads.
DSP + IGBT Technology: High-speed digital control and robust IGBT inverter for stable performance.
Wide Input Voltage Range: Suitable for areas with poor or fluctuating mains quality.
LCD/Touch Display: Real-time system status (voltage, load, battery) on 4.3 or similar screen.
Generator Compatible: Can work with standby diesel generator supply.
Frequency Mode: 50Hz (or 60Hz) synchronized or fixed in battery mode.
External Battery Bank: Battery modules are connected externally typical DC voltage 192 V ().
Protection & Operation
Overload protection against excessive load
Short-circuit protection
Hot standby & cold start support
Static & maintenance bypass switches
Reverse phase/neutral-less detection immunity
These features ensure the UPS continues to supply clean power even in harsh electrical environments.
Battery & Backup Notes
The UPS itself does not include batteries you must connect a compatible external battery bank (often VRLA/SMF) to provide backup runtime. Typical setups use 3240 batteries for a 192 V DC system on a 30 kVA unit.
Battery backup time depends on the number of batteries and their AH rating. Longer runtime requires larger battery banks.
Typical Specifications (Example)
| Feature | Typical Value |
|---|---|
| Capacity | 30 kVA |
| Input Voltage | 3380415 VAC (3Ph+N) |
| Output Voltage | 3380415 VAC (3Ph+N) |
| Frequency Range | 4654Hz (sync) |
| Power Factor | 0.99 |
| Output Regulation | 1 % (battery mode) |
| Efficiency | 95 %+ |
| Display | Smart LCD |
| Protection | Overload, short circuit, temperature |
(Values indicative from typical Super Max+ series specs)
What It Doesnt Include
Built-in Isolation Transformer If you require galvanic isolation between input and output for very sensitive equipment, you should specify that option or add an external transformer.
Batteries Must be supplied and installed separately.
Ideal Applications
Data centers & servers
Industrial process controls & automation
Telecom equipment
Medical devices & labs
Sensitive industrial loads
