MAX LIFE 5 KVA ONLINE UPS

Name: MAX LIFE 5 KVA ONLINE UPS
Brand: NAIVE POWER PROJECTS PVT LTD
Price: 68403.0 INR
Availability: InStock

68403.0 INR/Unit

Get a Price/Quote

Product Details:

Product Type online ups
Standard Safety Standards IEC/EN 62040 1: Safety requirements for UPS systems. IS/IEC 60950 1: Safety of information technology equipment. EMC / Electrical Compatibility IEC/EN 62040 2: Electromagnetic compatibility for UPS. Meets limits for conducted and radiated emissions. Performance / Quality IEC/EN 62040 3: Performance and test methods for UPS. ISO 9001 / ISO 14001 certified manufacturer (Microtek). Battery Standards Lead acid batteries conform to IS 15549 / IEC 60896 21/22. Lithium ion compatible batteries follow IEC 62133 safety requirements. Environmental Standards RoHS compliant: Restriction of hazardous substances. WEEE compliant: Waste Electrical and Electronic Equipment directive. Other Features Generator compatible (meets standards for stable operation with gensets). Designed for indoor use at 0 40 C and 0 95 % non-condensing humidity.
Frequency (MHz) 50hz Hertz (HZ)
Protection Protection Features MAX LiFe 5 KVA Online UPS Overload Protection Automatically limits current if load exceeds rated capacity, preventing damage to UPS and connected devices. Short-Circuit Protection Detects and immediately disconnects the output in case of a short-circuit to prevent damage or fire hazards. Overvoltage & Undervoltage Protection Protects connected equipment from voltage spikes or dips outside safe limits. Battery Overcharge / Deep Discharge Protection Prevents battery damage by controlling charge/discharge limits; prolongs battery life. Surge & Spike Protection Safeguards electronics from sudden transient voltage surges caused by lightning or mains fluctuations. Thermal / Over Temperature Protection Shuts down or throttles UPS operation if internal temperature exceeds safe limits. Reverse Polarity Protection Ensures the UPS or connected battery isn t damaged if battery is connected incorrectly. Automatic Bypass / Generator Compatible In case of internal fault, UPS automatically switches to bypass mode to continue supplying mains power. LED / LCD Fault Indication Alerts user about overload, battery fault, or other abnormal conditions for quick corrective action.
Usage backup
Size Dimensions (L W H): ~465 mm 190 mm 318 mm (approx.) standard chassis size for the UPS
Warranty 1 year
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

MAX LIFE 5 KVA ONLINE UPS Price And Quantity

Price 68403.0 INR/Unit
Minimum Order Quantity 1 Unit

MAX LIFE 5 KVA ONLINE UPS Product Specifications

Features Core Performance & Output True Double Conversion Online Technology continuous power conversion with zero break transfer to battery. Pure Sine Wave Output clean output safe for all sensitive electronics. Unity Power Factor delivers maximum usable power to connected loads. Wide Input Voltage Range stable operation even with fluctuating mains. Battery & Charging Supports 48 V External Batteries (lead acid or lithium ion compatible). Configurable Charging Current via LCD set charger current to match battery capacity. Powerful 60 A AC Charger for faster recharge. Cold Start Functionality UPS can start directly from battery when mains is absent. Smart & Scalable Intelligent LCD Display shows load, battery level, operating mode (AC/Battery/Bypass), and fault alerts. Optional Parallel Operation (in some models) allows multiple UPS units for extra capacity or redundancy (up to 9 units). Protection & Compatibility Generator Compatible works smoothly with gensets. Overload and Short Circuit Protection protects both UPS and connected equipment. Advanced Battery Management (ABM) protects batteries, improves life & performance (especially for lithium ion). Efficiency & Design High Efficiency reduces energy losses and heat. Stable Output Waveform low harmonic distortion and clean power. Suitable for Critical Loads ideal for servers, networking gear, CCTV/DVR, home offices, and small business systems.
Usage backup
Frequency (MHz) 50hz Hertz (HZ)
Standard Safety Standards IEC/EN 62040 1: Safety requirements for UPS systems. IS/IEC 60950 1: Safety of information technology equipment. EMC / Electrical Compatibility IEC/EN 62040 2: Electromagnetic compatibility for UPS. Meets limits for conducted and radiated emissions. Performance / Quality IEC/EN 62040 3: Performance and test methods for UPS. ISO 9001 / ISO 14001 certified manufacturer (Microtek). Battery Standards Lead acid batteries conform to IS 15549 / IEC 60896 21/22. Lithium ion compatible batteries follow IEC 62133 safety requirements. Environmental Standards RoHS compliant: Restriction of hazardous substances. WEEE compliant: Waste Electrical and Electronic Equipment directive. Other Features Generator compatible (meets standards for stable operation with gensets). Designed for indoor use at 0 40 C and 0 95 % non-condensing humidity.
Frequency 50 Hertz (HZ)
Rated Current 5000 VA Volt (v)
Color black
Operating Temperature 0 40 C Celsius (oC)
Dimension (L*W*H) (L W H): 53 cm 14.5 cm 22 cm Centimeter (cm)
Weight 12.1 Kilograms (kg)
Cable Type thick multi core power cable (typically 3 core: live, neutral, earth) / hard wired terminals
Rated Voltage 220 V AC Volt (V)
Conductor Conductor / Cable Guidelines AC Input Conductor (Mains Supply) Type: Multi-core, flexible copper conductor (H05VV-F / ISI 694:1986 standard in India) Core Count: 3-core (Live, Neutral, Earth) Recommended Size: 4 mm 6 mm copper (depending on distance and load, rated for ~22 25 A) Insulation: PVC, rated for 300 500 V AC AC Output Conductor (Load Side) Type: Multi-strand copper or armored cable for higher safety Core Count: Single-phase, usually 3-core or individual cables per phase + neutral + earth Recommended Size: 2.5 mm 4 mm copper for typical office/server loads (~20 A) Termination: Properly crimped lugs or sockets Battery / DC Conductor (48 V Battery Bank) Type: Flexible, thick copper cable with low resistance Recommended Size: 25 35 mm (depending on battery Ah and distance) Insulation: Heat-resistant PVC or XLPE Termination: Crimped lugs + proper torque; fuse or breaker close to battery for protection Earth / Ground Conductor Type: Solid or stranded copper wire Recommended Size: 4 mm copper Connection: UPS chassis to building earth/ground rod
Size Dimensions (L W H): ~465 mm 190 mm 318 mm (approx.) standard chassis size for the UPS
Usage & Applications power supply
Protection Protection Features MAX LiFe 5 KVA Online UPS Overload Protection Automatically limits current if load exceeds rated capacity, preventing damage to UPS and connected devices. Short-Circuit Protection Detects and immediately disconnects the output in case of a short-circuit to prevent damage or fire hazards. Overvoltage & Undervoltage Protection Protects connected equipment from voltage spikes or dips outside safe limits. Battery Overcharge / Deep Discharge Protection Prevents battery damage by controlling charge/discharge limits; prolongs battery life. Surge & Spike Protection Safeguards electronics from sudden transient voltage surges caused by lightning or mains fluctuations. Thermal / Over Temperature Protection Shuts down or throttles UPS operation if internal temperature exceeds safe limits. Reverse Polarity Protection Ensures the UPS or connected battery isn t damaged if battery is connected incorrectly. Automatic Bypass / Generator Compatible In case of internal fault, UPS automatically switches to bypass mode to continue supplying mains power. LED / LCD Fault Indication Alerts user about overload, battery fault, or other abnormal conditions for quick corrective action.
Phase single phase
Warranty 1 year
Product Type online ups
Material steel
Display Type LCD (Liquid Crystal Display) shows important UPS information such as: Load level Battery level Operating mode (AC/Battery/Bypass) Fault and warning indicators Configurable settings menu (charging, alarms, etc.

MAX LIFE 5 KVA ONLINE UPS Trade Information

Delivery Time 7 Days

Product Description

Overview Microtek MAX LiFe 5KVA Online UPS

The Microtek MAX LiFe 5KVA UPS is a true online doubleconversion UPS designed to provide uninterrupted clean power and protect sensitive electrical equipment from voltage dips, surges, and outages.

Key Highlights Microtek MAX LiFe 5KVA Online UPS

True Online DoubleConversion Technology provides continuous, clean AC power with zero switchover delay.
Pure Sine Wave Output safe for sensitive electronics like servers, PCs, and networking devices.
Wide Input Voltage Range operates reliably under fluctuating mains voltage.
48V External Battery Support compatible with lead-acid (SMF) and lithium-ion batteries.
Powerful 60A Charger configurable via LCD for faster battery charging.
Cold Start Capability UPS can start directly from battery during power outages.
High Efficiency (>90%) maintains stable performance under full load.
Seamless Transfer (<0ms) uninterrupted power during mains failure.
LCD Display shows load, battery status, operating mode, and faults.
Generator Compatible works smoothly with backup gensets.
Built-In Protection safeguards against overload, short-circuit, and voltage surges.

Compact & Robust Design suitable for offices, home workstations, and small servers.

Specification	Details
Output Capacity	5KVA / 4.5kW (0.9PF)
Output Phase	Single Phase
Output Voltage	208V / 220V
Output Waveform	Pure Sine Wave
Output Voltage Distortion (THD)	<23%
Output Frequency	50/60Hz (sync) 3Hz; Battery mode 0.1%
Transfer Time	<0ms (instant)
Efficiency (Full Load)	>90%
Input Voltage	240V AC
Input Phase	Single Phase
Input Voltage Range	119295V (derated); 160285V typical
Input Frequency Range	4654Hz
Input Power Factor	>0.99
Battery DC Bus	48V DC
Maximum Charger Capacity	60A (configurable via LCD)
Battery Position	External
Battery Type Supported	SMF / LeadAcid (lithiumion compatible)
Load Crest Factor	3:1
Noise Level	<50dB at 1m
Dimensions (WDH)	190421336mm
Net Weight	12.1kg
Operating Temp. Range	040C
Transfer Type	True Online Double Conversion
Cold Start Support	Yes
Generator Compatible	Yes
LCD Display	Load, battery, modes, fault indicators

warranty :- 1 year
Notes:
Actual backup time depends on the battery bank size (Ah rating) you use with the UPS.
Specifications may vary slightly by seller or submodel always check the datasheet/product manual before buying.
