ELNOVA (20k33) 20KVA 3:3 PHASE ONLINE UPS

Name: ELNOVA (20k33) 20KVA 3:3 PHASE ONLINE UPS
Brand: NAIVE POWER PROJECTS PVT LTD
Price: 158200.0 INR
Availability: InStock

158200.0 INR/Piece

Get a Price/Quote

Product Details:

Power Rating 20KVA
Product Type ELNOVA (20k33) 20KVA 3:3 PHASE ONLINE UPSLive
Standard 250 868 828 mm
Frequency (MHz) 45 55 Hz Hertz (HZ)
Protection IP20
Usage BACKUP
Size STANDARD
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

ELNOVA (20k33) 20KVA 3:3 PHASE ONLINE UPS Price And Quantity

Minimum Order Quantity 1 Unit
Price 158200.0 INR/Piece

ELNOVA (20k33) 20KVA 3:3 PHASE ONLINE UPS Product Specifications

Frequency (MHz) 45 55 Hz Hertz (HZ)
Display Type LCD + LED
Weight 64 Kilograms (kg)
Power Rating 20KVA
Product Type ELNOVA (20k33) 20KVA 3:3 PHASE ONLINE UPSLive
Usage BACKUP
Operating Temperature 0 C to 40 C Celsius (oC)
Cable Type 4C 10 sq.mm or 5C 10 sq.mm (with neutral & earth)
Frequency 45 55 Hz Hertz (HZ)
Rated Current 28.9 A Ampere (amp)
Standard 250 868 828 mm
Rated Voltage 400 V AC (380/415 V s Volt (V)
Material STEEL
Warranty 1 YEAR
Phase 3:3
Protection IP20
Color BLACK
Size STANDARD
Features True Online Double Conversion Technology
Dimension (L*W*H) 250 868 828 mm Millimeter (mm)
Usage & Applications POWER SUPPLY

ELNOVA (20k33) 20KVA 3:3 PHASE ONLINE UPS Trade Information

Delivery Time 7 Days

Product Description

The Elnova 20K33 series is a 20 kVA, 3-phase input / 3-phase output Online UPS designed for critical industrial and commercial power backup applications. It uses true double-conversion technology to provide continuous, clean, and stable power without interruption.

Specification Table ELNOVA 20K33 (20 kVA Online UPS)

Specification	Details
Model	ES20K33 / KL20K33
Capacity	20 kVA
Active Power	1618 kW (depends on PF: 0.80.9)
Topology	Online Double Conversion UPS
Phase	3 Phase Input / 3 Phase Output (3:3)
Output Voltage	380V / 400V / 415V AC (selectable)
Input Voltage Range	300V 480V AC
Frequency	50 / 60 Hz (auto sensing)
Power Factor	0.8 0.9
Efficiency	> 93%
Output Waveform	Pure Sine Wave
THD (Output)	< 3% (linear load)
Crest Factor	3:1
Battery DC Bus	384V 480V DC (external battery bank)
Battery Type	SMF / Lead Acid
Charging Current	Up to 20A (model dependent)
Bypass	Static & Maintenance Bypass
Isolation Transformer	Optional (standard in KL series)
Display	LCD + LED Control Panel
Protection	Overload, Short Circuit, Overcharge, Deep Discharge
Communication	RS-232 / USB / SNMP (optional)
Parallel Operation	Up to 4 units (ES series)
Cooling	Forced air cooling (fan-based)
Operating Temp	0C 40C
Application	Data centers, hospitals, industries, telecom, automation

If you want, I can also make:

Battery backup chart (how many batteries & runtime)
Wiring diagram (3-phase input/output connection)
Full installation cost estimate in India
ES20K33 vs KL20K33 difference (simple comparison)

Advanced Power Protection for Critical Applications

The ELNOVA (20k33) 20KVA 3:3 Phase Online UPS is designed to protect essential equipment from power fluctuations and outages. Its true online double conversion technology ensures continuous and stable output voltage, making it ideal for data centers, industrial operations, and large commercial enterprises.

User-Friendly Features and Flexible Installation

Featuring both LCD and LED display panels, the UPS provides real-time status updates for ease of monitoring. Its compatibility with 4C 10 sq.mm or 5C 10 sq.mm cables supports various installation configurations. The unit's robust steel build and IP20 protection rating provide safety and longevity in diverse environments.

FAQ's of ELNOVA (20k33) 20KVA 3:3 PHASE ONLINE UPS:

Q: How does the ELNOVA (20k33) 20KVA Online UPS provide reliable power backup?

A: This UPS employs true online double conversion technology, which continuously converts incoming AC power to DC and then back to AC, eliminating fluctuations and providing seamless backup during power disturbances or outages.

Q: What are the installation requirements for the ELNOVA 20k33 UPS?

A: The unit requires a 3-phase input and output connection (3:3), with compatible cable types being 4C 10 sq.mm or 5C 10 sq.mm (including neutral and earth). The UPS should be installed in a location with ambient temperatures between 0C and 40C for optimal performance.

Q: When should I use the ELNOVA 20KVA UPS?

A: This UPS is best utilized in scenarios demanding continuous, high-quality power supply, such as data centers, manufacturing facilities, telecom operations, or any environment with critical systems requiring protection from voltage sags, surges, or interruptions.

Q: Where can I deploy the ELNOVA (20k33) UPS in my facility?

A: With its standard dimensions and floor-standing design, the UPS can be positioned in server rooms, equipment bays, or near electrical distribution boards-provided adequate ventilation is ensured and the temperature remains within the specified range.

Q: What is the process for monitoring the UPS operation?

A: The ELNOVA UPS features both LCD and LED display panels, enabling you to easily check real-time operating conditions, power status, input/output voltage, and system alerts, ensuring proactive maintenance and fault management.

Q: How does the ELNOVA (20k33) 20KVA UPS benefit critical operations?

A: By delivering stable, uninterrupted power and offering protection against surges, sags, and blackouts, the UPS safeguards sensitive electronics, reduces the risk of data loss, and enhances the uptime and reliability of your critical operations.
