ELNOVA (15k33) 15KVA 3:3 PHASE ONLINE UPS

170200.0 INR/Piece

Get a Price/Quote

Product Details:

Power Rating 15KVA
Product Type ELNOVA (15k33) 15KVA 3:3 PHASE ONLINE UPS
Standard Parameter Standard Value Width (W) 530 mm Depth (D) 859 mm Height (H) 1010 mm Form Factor Tower / Floor Standing Weight (approx.) 330 350 kg
Frequency (MHz) 50 / 60 Hz Hertz (HZ)
Protection IP20
Usage BACKUP
Size STANDARD
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

ELNOVA (15k33) 15KVA 3:3 PHASE ONLINE UPS Price And Quantity

Minimum Order Quantity 1 Unit
Price 170200.0 INR/Piece

ELNOVA (15k33) 15KVA 3:3 PHASE ONLINE UPS Product Specifications

Power Rating 15KVA
Standard Parameter Standard Value Width (W) 530 mm Depth (D) 859 mm Height (H) 1010 mm Form Factor Tower / Floor Standing Weight (approx.) 330 350 kg
Phase 3:3
Frequency 50 / 60 Hz Hertz (HZ)
Frequency (MHz) 50 / 60 Hz Hertz (HZ)
Rated Current 21.7 A Ampere (amp)
Size STANDARD
Dimension (L*W*H) Width (W) ~ 530 mm Depth (D) ~ 859 mm Height (H) ~ 1010 mm Millimeter (mm)
Display Type LCD + LED Interface
Material STEEL
Operating Temperature 0 C 40 C Celsius (oC)
Protection IP20
Weight 330 350 kg Kilograms (kg)
Rated Voltage 380 / 400 / 415 VAC Volt (V)
Usage & Applications POWER SUPPLY
Cable Type Copper XLPE Armoured Cable (4 Core / 5 Core)
Warranty 1 YEAR
Usage BACKUP
Product Type ELNOVA (15k33) 15KVA 3:3 PHASE ONLINE UPS
Color BLACK
Features True Online Double Conversion Technology for continuous power protection

ELNOVA (15k33) 15KVA 3:3 PHASE ONLINE UPS Trade Information

Delivery Time 7 Days

Product Description

The ELNOVA 15K33 is a three-phase input, three-phase output (3:3 phase) online double-conversion UPS designed to provide uninterrupted, clean, and regulated power for critical equipment. It uses advanced DSP-controlled technology with active power factor correction to ensure high efficiency, stable output voltage, and protection against power disturbances such as outages, voltage fluctuations, surges, spikes, and frequency variations.

Specification Table

Specification	Details
Model	ELNOVA 15K33
Capacity	15 kVA / 13.5 kW
Topology	Online Double Conversion
Phase	3 Phase Input / 3 Phase Output (3:3)
Input Voltage	380 / 400 / 415 VAC (3-phase)
Input Frequency	50 / 60 Hz (auto sensing)
Input Power Factor	0.99
Input Voltage Range	~300480 VAC (operational range varies by load)
Output Voltage	380 / 400 / 415 VAC
Output Power Factor	0.9
Output Waveform	Pure Sine Wave
Output Frequency	50 / 60 Hz (sync 0.1 Hz in battery mode)
Efficiency	> 93% at full load
Output THD	< 3% (linear load)
Crest Factor	3:1
Battery DC Bus	384 480 VDC
Battery Type	SMF / External battery bank
Charger Current	Up to ~20A (configurable)
Bypass	Static & Automatic Bypass
Communication	RS-232, USB
SNMP Support	Optional
Display	LCD + LED Interface
Parallel Operation	Up to 4 units
Protection Class	IP20
Operating Temperature	0C 40C
Humidity	095% (non-condensing)
Cooling	Forced air cooling (internal fans)
Installation	Floor standing (tower type)
