ELNOVA (60k33) 60KVA 3:3 PHASE ONLINE UPS

Product Description

ELNOVA 60K33 (60 kVA, 3-Phase In / 3-Phase Out Online UPS) Description

The ELNOVA 60K33 is a high-frequency, true online double-conversion UPS designed to provide uninterrupted and conditioned power for critical industrial, commercial, and IT applications. It uses DSP-based digital control technology and active input power factor correction to deliver stable output voltage, high efficiency, and protection against power disturbances such as outages, surges, spikes, harmonics, and voltage fluctuations.

ELNOVA 60K33 (60 kVA, 3:3 Phase Online UPS) Specifications

Specification	Details
Model	ELNOVA ES60K33 / KL60K33
UPS Type	True Online Double Conversion
Capacity	60 kVA
Output Power	48 kW
Input Phase	3 Phase + Neutral + Ground
Output Phase	3 Phase + Neutral + Ground
Input Voltage	380/400/415 VAC (Line-Line)
Input Voltage Range	304478 VAC (Full Load)
Input Frequency	4070 Hz
Input Power Factor	> 0.99
Input Current THDi	< 3%
Output Voltage	380/400/415 VAC
Voltage Regulation	1% (Balanced Load)
Output Frequency	50/60 Hz
Frequency Accuracy	0.1%
Output Waveform	Pure Sine Wave
Crest Factor	3:1
Output THD	<1% (Linear Load), <5.5% (Non-Linear Load)
Overload Capacity	110% for 1 hour, 125% for 10 min, 150% for 1 min
Battery Voltage	240 VDC (480 VDC Bus)
Battery Quantity	40 Batteries (12V each, configurable)
Charging Capacity	Up to 20% of Output Active Power
Cold Start	Supported
Efficiency (Online Mode)	Up to 9596%
ECO Mode Efficiency	Up to 99%
Display	7" LCD Touch Screen + LED Indicators
Communication Ports	RS232, RS485, USB, Dry Contact
Optional Interfaces	SNMP Card, Parallel Kit, SPD, LBS
Parallel Operation	Up to 68 Units (depending on configuration)
Protection Class	IP20
Operating Temperature	0C to 40C
Storage Temperature	-40C to 70C
Relative Humidity	095% (Non-Condensing)
Noise Level	60 dB @ 1 Meter
Dimensions (W D H)	600 980 950 mm
Weight	Approximately 170 kg
Transfer Time	0 ms
Applications	Data Centers, Hospitals, Telecom, Industrial Automation, Banking, IT Infrastructure

Product Description:
The ELNOVA 60K33 is a three-phase online UPS designed for mission-critical applications requiring uninterrupted and clean power. It features DSP-based digital control, high input power factor correction, low harmonic distortion, advanced battery management, and scalable parallel redundancy, making it suitable for industrial plants, server rooms, telecom networks, healthcare facilities, and commercial infrastructure.
