ELNOVA (ES10000) 10KVA 1:1 PHASE ONLINE UPS
Product Details:
- Product Type ELNOVA (ES10000) 10KVA 1:1 PHASE ONLINE UPS
- Power Rating 10kva
- Standard ~480 220 438 mm
- Frequency (MHz) 40 70 Hz Hertz (HZ)
- Protection Overload, short circuit, over/under voltage, over temperature
- Usage backup
- Size standard
- Click to View more
ELNOVA (ES10000) 10KVA 1:1 PHASE ONLINE UPS Price And Quantity
- 1 Piece
- 71500.0 INR/Piece
ELNOVA (ES10000) 10KVA 1:1 PHASE ONLINE UPS Product Specifications
- 43.47A Ampere (amp)
- ~480 220 438 mm Millimeter (mm)
- 10kva
- LCD + LED Status Panel
- Type: Copper, multi-strand flexible cable
- 25 Kilograms (kg)
- ~480 220 438 mm
- Overload, short circuit, over/under voltage, over temperature
- power supply
- steel
- : 220V / 230V / 240V AC Volt (V)
- black
- 40 70 Hz Hertz (HZ)
- 0 C to 40 C Celsius (oC)
- 1year
- backup
- standard
- 1:1 phase
- 40 70 Hz Hertz (HZ)
- ELNOVA (ES10000) 10KVA 1:1 PHASE ONLINE UPS
- Provides continuous power conditioning with zero transfer time.
ELNOVA (ES10000) 10KVA 1:1 PHASE ONLINE UPS Trade Information
- 7 Days
Product Description
The Elnova ES10000 is a 10KVA true online double-conversion UPS designed to provide reliable, clean, and uninterrupted power for critical electrical and IT systems. It continuously converts incoming AC power to DC and then back to AC, ensuring stable pure sine wave output with zero transfer time, which protects sensitive equipment from voltage fluctuations, surges, and power failures.
This UPS uses DSP-based digital control technology along with IGBT-based rectifier and inverter stages, delivering high efficiency, improved power factor, and strong performance under unstable grid conditions. It also includes Power Factor Correction (PFC) to optimize input power usage.
The system supports an external battery bank (typically 192V DC), allowing flexible backup time depending on the number and capacity of batteries used. It is compatible with generators and offers advanced battery charging management to extend battery life.
A built-in LCD + LED display panel provides real-time monitoring of input/output voltage, load level, battery status, operating mode, and fault conditions. It also includes protections such as overload, short circuit, over-temperature, and low battery shutdown.
The ES10000 is widely used in environments requiring continuous power such as servers, data centers, telecom systems, medical equipment, and industrial automation systems.
| Specification | Details |
|---|---|
| Model | ES10000 |
| Capacity | 10 KVA / 9 KW |
| Phase | 1 Phase In / 1 Phase Out (1:1) |
| Technology | Online Double Conversion (DSP controlled) |
| Output Waveform | Pure Sine Wave |
| Power Factor | 0.9 0.99 (model dependent) |
| Efficiency | >88% up to 94% |
| Input Voltage Range | 160V 280V (approx.) |
| Input Frequency | 40 70 Hz |
| Output Voltage | 220V / 230V / 240V (configurable) |
| Output Frequency | 50 / 60 Hz (auto sync) |
| Battery System | External Battery Bank |
| DC Bus Voltage | 192V DC |
| Battery Type | SMF / Lead Acid Batteries |
| Charging Current | 10A (model dependent) |
| Transfer Time | 0 ms (online mode) |
| Display | LCD + LED Panel |
| Communication Ports | RS232 / USB (optional SNMP, RS485) |
| Protection Features | Overload, short circuit, over/under voltage, over temperature |
| Cooling | Intelligent fan cooling |
| Noise Level | <55 dB |
| Operating Temperature | 0C 40C |
| Relative Humidity | 0% 95% (non-condensing) |
| Applications | Data centers, servers, telecom, medical, industrial loads |
| Dimensions | 480 220 438 mm |
| Weight | 2025 kg (UPS unit only) |
