BPE (HXi3120L30) 20KVA ONLINE UPS INBUILT Isolation Transfarmer

140184.0 INR/Unit

Get a Price/Quote

Product Details:

Power Rating 20 KVA
Product Type BPE (HXi3120L30) 20KVA ONLINE UPS INBUILT Isolation Transfarmer
Standard 615 280 685 mm
Frequency (MHz) 60 Hertz (HZ)
Protection Overload, Short Circuit, Over Temperature, Battery Protection
Usage BACKUP
Size STANDARD
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

BPE (HXi3120L30) 20KVA ONLINE UPS INBUILT Isolation Transfarmer Price And Quantity

Price 140184.0 INR/Unit
Minimum Order Quantity 1 Unit

BPE (HXi3120L30) 20KVA ONLINE UPS INBUILT Isolation Transfarmer Product Specifications

Usage & Applications POWER SUPPLY
Frequency (MHz) 60 Hertz (HZ)
Rated Current 70 75 Amps Ampere (amp)
Frequency 50 Hertz (HZ)
Phase 3 PHASE
Display Type Multi-function LCD panel
Dimension (L*W*H) 615 280 685 mm Millimeter (mm)
Color BLACK
Product Type BPE (HXi3120L30) 20KVA ONLINE UPS INBUILT Isolation Transfarmer
Operating Temperature 0 C 40 C Celsius (oC)
Size STANDARD
Features Online Double Conversion UPS 20 KVA / 16 KW high capacity output Built-in Isolation Transformer for clean & safe power Zero transfer time (0 ms) no power interruption Pure sine wave output for sensitive equipment High efficiency (>94%) 3-phase input / 1-phase output system Wide input voltage range (285V 470V) Power factor > 0.99 (input)
Weight 88 Kilograms (kg)
Standard 615 280 685 mm
Cable Type Type: Copper XLPE / FRLS insulated cable
Warranty 1 YEAR
Rated Voltage 415V AC Volt (V)
Power Rating 20 KVA
Protection Overload, Short Circuit, Over Temperature, Battery Protection
Usage BACKUP
Material STEEL

BPE (HXi3120L30) 20KVA ONLINE UPS INBUILT Isolation Transfarmer Trade Information

Delivery Time 7 Days

Product Description

BPE HXi3120L30 20KVA Online UPS with Inbuilt Isolation Transformer

The BPE HXi3120L30 is a 20KVA (16KW) three-phase to single-phase online UPS system designed for critical power applications where uninterrupted, clean, and stable power is required. It uses double-conversion online technology with 0 ms transfer time, ensuring continuous power without any interruption during mains failure.|

Specification Table

Parameter	Details
Model	HXi3120L30
Brand	BPE
Capacity	20 KVA / 16 kW
Technology	Online Double Conversion UPS
Input Phase	3 Phase Input
Output Phase	1 Phase Output
Output Voltage	220 / 230 / 240 V AC
Frequency	50/60 Hz 3 Hz
Power Factor	0.8
Efficiency	>94%
Transfer Time	0 ms (No break power)
Waveform	Pure Sine Wave
Crest Factor	3:1
Voltage Distortion (THD)	< 3%
Bypass	Internal (Automatic & Manual)
Isolation Transformer	Inbuilt
Input Voltage Range	285 470 V AC
Input Frequency Range	40 70 Hz
DC Bus Voltage	360 V DC
Battery Type	SMF / Flooded Batteries
Battery Configuration	External Battery Bank
Charger Capacity	Up to 10 Amp
Recharge Time	< 10 hours to 90%
Display	Multi-function LCD panel
Monitoring	SNMP / RS-232 Support
Protection	Overload, Short Circuit, Over Temperature, Battery Low/High
Noise Level	< 56 dB
Weight	~88 kg
Dimensions (WDH)	615 280 685 mm
Operating Temp	0C to 40C

WARRANTY :- 1 YEAR
