ELNOVA (160k33) 160KVA 3:3 PHASE ONLINE UPS
1780867.0 INR/Piece
Product Details:
- Power Rating 160KVA
- Product Type ELNOVA (160k33) 160KVA 3:3 PHASE ONLINE UPS
- Standard . 600 900 2000 mm
- Frequency (MHz) 50 / 60 Hz Hertz (HZ)
- Protection Overload, short circuit, over/under voltage, over temperature
- Usage BACKUP
- Size STANDARD
- Click to View more
X
ELNOVA (160k33) 160KVA 3:3 PHASE ONLINE UPS Price And Quantity
- 1 Unit
- 1780867.0 INR/Piece
ELNOVA (160k33) 160KVA 3:3 PHASE ONLINE UPS Product Specifications
- FRLS / FRLSH PVC insulated, armoured cable (XLPE optional for better performance)
- BACKUP
- 160KVA
- . 600 900 2000 mm
- STANDARD
- LCD / LED monitoring panel
- Overload, short circuit, over/under voltage, over temperature
- 223 A Ampere (amp)
- . 600 900 2000 mm Millimeter (mm)
- 550 Kilograms (kg)
- 50 / 60 Hz Hertz (HZ)
- 1 YEAR
- 0 C to 40 45 C Celsius (oC)
- 3:3 PHASE
- 50 / 60 Hz Hertz (HZ)
- STEEL
- ELNOVA (160k33) 160KVA 3:3 PHASE ONLINE UPS
- 380 / 400 / 415 VAC Volt (V)
- POWER SUPPLY
- https://chatgpt.com/#:~:text=Provides%20continuous%2C%20clean%2C%20and%20regulated%20power%20with%20zero%20interruption%20(0%20ms%20transfer%20time).
- BLACK
ELNOVA (160k33) 160KVA 3:3 PHASE ONLINE UPS Trade Information
- 7 Days
Product Description
Description ELNOVA 160K33 (160 kVA 3:3 Phase Online UPS)
The ELNOVA 160K33 is a 160 kVA three-phase (3:3) online double-conversion UPS system designed to deliver continuous, clean, and stable power for critical industrial and IT applications.
It converts incoming AC power to DC and then back to AC using an inverter, ensuring zero transfer time (0 ms) during power failure, so connected equipment never experiences interruption.
This model is typically used in environments where power reliability is essential, such as data centers, hospitals, manufacturing plants, telecom systems, and large commercial facilities.
| Specification | Details |
|---|---|
| Model | ELNOVA 160K33 (ES Series / 3 Phase Online UPS) |
| Capacity | 160 kVA / 160 kW (approx.) |
| Topology | Online Double Conversion |
| Phase | 3 Phase Input / 3 Phase Output (3:3) |
| Input Voltage | 380 / 400 / 415 VAC (Line to Line) |
| Input Range | ~152 528 VAC (wide range) |
| Input Frequency | 50 / 60 Hz (auto sensing) |
| Output Voltage | 380 / 400 / 415 VAC (configurable) |
| Output Frequency | 50 / 60 Hz |
| Power Factor | Up to 0.99 (input) |
| Output Power Factor | 0.8 1.0 (depending load) |
| Efficiency | Up to 95% (online mode), higher in ECO mode |
| Transfer Time | 0 ms (continuous online supply) |
| Output Waveform | Pure Sine Wave |
| THD (Output) | < 3% (linear load) |
| Battery Type | External VRLA / Lithium-ion |
| Battery Bank Voltage | Typically 384V / 480V DC (configurable) |
| Battery Backup | Depends on external battery sizing |
| Charging Method | Smart float / boost charging |
| Bypass System | Static & maintenance bypass available |
| Display | LCD / LED monitoring panel |
| Communication | RS232, RS485, Dry contact (SNMP optional) |
| Protection Features | Overload, short circuit, over/under voltage, over temperature |
| Overload Capacity | 110%150% with time-based support |
| Cooling | Forced air (fan cooling) |
| Operating Temperature | 0C to 4045C |
| Humidity | 095% non-condensing |
| Applications | Data centers, hospitals, telecom, industry, IT infrastructure |
If you want, I can also convert this into:
- PDF datasheet format
- Battery sizing chart (backup time vs load)
- Single Line Diagram (SLD)
- Full quotation (UPS + battery + installation)
