ELNOVA (100k33) 100KVA 3:3 PHASE ONLINE UPS

560000.0 INR/Piece

Get a Price/Quote

Product Details:

Product Type ELNOVA (100k33) 100KVA 3:3 PHASE ONLINE UPS
Power Rating 10kva
Standard Specification Details Height ~1400 mm Width ~600 mm Depth ~900 1000 mm Weight ~230 320 kg (UPS only, without batteries)
Frequency (MHz) 50 / 60 Hz Hertz (HZ)
Protection Overload, short circuit, over/under voltage, overheating
Usage BACKUP
Size Specification Details Height ~1400 mm Width ~600 mm Depth ~900 1000 mm Weight ~230 320 kg (UPS only, without batteries)
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

ELNOVA (100k33) 100KVA 3:3 PHASE ONLINE UPS Price And Quantity

Minimum Order Quantity 1 Unit
Price 560000.0 INR/Piece

ELNOVA (100k33) 100KVA 3:3 PHASE ONLINE UPS Product Specifications

Usage BACKUP
Phase 3:3 PHASE
Standard Specification Details Height ~1400 mm Width ~600 mm Depth ~900 1000 mm Weight ~230 320 kg (UPS only, without batteries)
Material steel
Features True Online Double Conversion UPS
Cable Type 3.5C 70 sq.mm Cu
Frequency 50 / 60 Hz Hertz (HZ)
Warranty 1 year
Weight 320 Kilograms (kg)
Frequency (MHz) 50 / 60 Hz Hertz (HZ)
Size Specification Details Height ~1400 mm Width ~600 mm Depth ~900 1000 mm Weight ~230 320 kg (UPS only, without batteries)
Power Rating 10kva
Rated Current 139 A Ampere (amp)
Color BLACK
Rated Voltage 380 / 400 / 415 VAC Volt (V)
Dimension (L*W*H) Specification Details Height ~1400 mm Width ~600 mm Depth ~900 1000 mm Weight ~230 320 kg (UPS only, without batteries) Millimeter (mm)
Display Type LCD / Touch screen monitoring
Product Type ELNOVA (100k33) 100KVA 3:3 PHASE ONLINE UPS
Protection Overload, short circuit, over/under voltage, overheating
Usage & Applications power supply
Operating Temperature 0 C to 40 C Celsius (oC)

ELNOVA (100k33) 100KVA 3:3 PHASE ONLINE UPS Trade Information

Delivery Time 7 Days

Product Description

ELNOVA 100K33 (100 kVA, 3:3 Phase Online UPS) is a high-capacity industrial true online double-conversion UPS system designed to provide uninterrupted, clean, and stable power for critical electrical loads.

It converts incoming AC power to DC and then back to AC, ensuring zero transfer time during power failures and complete isolation from grid disturbances like voltage fluctuations, surges, harmonics, and frequency variations.

ELNOVA 100K33 Specification Table

Specification	Details
Model	ELNOVA 100K33
Capacity	100 kVA / 100 kW (approx.)
Phase	3 Phase Input / 3 Phase Output (3:3)
UPS Type	Online Double Conversion
Power Factor	Up to 1.0 (load dependent)
Input Voltage	380 / 400 / 415 VAC (3P + N + G)
Input Frequency	50 / 60 Hz (Auto sensing)
Output Voltage	380 / 400 / 415 VAC
Output Frequency	50 / 60 Hz
Waveform	Pure Sine Wave
Efficiency	~93% 96% (varies by load)
Transfer Time	0 ms (online UPS)
Input Power Factor	0.99 (typical with PFC)
THDi (Input Distortion)	< 3% 5%
THDv (Output Distortion)	< 2% 3% (linear load)
Overload Capacity	110% (long), 125% (short), up to 150% (brief)
Battery Type	External Battery Bank
Battery Voltage	Configurable (typically 192V to 240V DC)
Control System	DSP-based digital control
Display	LCD / Touch screen monitoring
Protection	Overload, short circuit, over/under voltage, overheating
Cooling	Forced air cooling (internal fans)
Parallel Operation	Supported (model dependent)
Communication	RS232 / RS485 / SNMP (optional)
Operating Temperature	0C to 40C
Humidity	095% non-condensing
Applications	Data centers, hospitals, industry, telecom, IT infrastructure
